Customized PV Tracking System Backtracking with GPS Snow Wind Protection
Company Introduction
Good Future Solar is a professional solar tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
How do solar trackers work?
The orientation of the tracking system can either be controlled by a pre-programmed path based on astronomic predictions, or use solar radiation sensors to react to the current position of the sun. Good Future Solar tracking system use “Astronomical algorithm + closed-loop control” to make sure a precise tracking angle. We don’t use Sensors because it will become disorientated at dawn and in cloudy conditions, so a backup tracking system is necessary in the latter case.
Product Introduction
Good Future Smart Solar Tracking System uses high precision tracking method “Astronomical algorithm + closed-loop control”, to calculate the angle of the sun, under the control of slew driver and controller system, the PV panels will rotate tracking with the sunlight, this making the system more accurate and reliable, not rainy days,snow days and other bad weather interference,using international first-line brand tilt sensor, real-time closed-loop feedback tracking angle, automatic tracking, without human intervention.
Parameters of Smart Solar Tracking System
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
Choose Good Future Solar Smart Solar Tracking System will Provide Some Advantages:
- Adapt to outdoor environment,working temperature -40~80C°.
- Hot-dipped zinc galvanization will extend the work life of the brackets
- Automatic control: The solar tracking system will provide protection automatically for different weather (rain, snow, high winds, etc. )
- Weight-lifting structure with 5 supporting points, shaped table design combined with a four-link age structure,driven by slewing drive.
- The structure is simple, the parts are highly pre assembled, and the construction time is saved.
- Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
Customized Functions
Rain and snow mode
Lora/CAN
Self-powered
Steel frame basis
Surroundings adapt custom made
According to Customer request custom made
