Customized Single Axis Solar Tracker Ground Solar PV Panel Mounting Bracket

Name: Customized Single Axis Solar Tracker Ground Solar PV Panel Mounting Bracket
Brand: Good Future Solar
Price: 1 USD

Quality Customized Single Axis Solar Tracker Ground Solar PV Panel Mounting Bracket wholesale

Brand Name : Good Future Solar

Model Number : MG/ZG/YG/JG.ETC

Certification : CE/ISO/BV/SGS or designated

Place of Origin : China

MOQ : Negotiate

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000MW per Month

Delivery Time : 30 Working Days after design confirm

Packaging Details : Neutral packing

Product : Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket

Driving System : Slew drive for tracker

Operation Temperature : -40℃ - 70℃

String-Power : Yes

Damper : Included

Material : Galvanized Steel

Model : 1p or 2p

Control Algorithm : Astronomical algorithms + Tilt sensor

Contact Now

Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket

Working principle:
1. The structure is simple, the parts are highly pre assembled, and the construction time is saved.
2. Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
3. Strong wind protection, optional with rain cleaning mode, automatic snow removal mode.
4. IP66 aviation plug connection is adopted, and the system is free of debugging.
5. It can communicate with the inverter in real time, read the output data of the inverter and calculate the best tracking angle.
6. Photovoltaic power generation can be increased by 24-43%.

Functions:

1) It can respond to site features and changing weather conditions, and conditions to continuously optimizing the tracking algorithm of each individual row, to make boost solar power system production.
2) The most promising product technology trends in solar today. which help users get more power generated.
3) Simple structure ,easy in installation and debugger application.

Technical Parameters of single axis solar tracking system

Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket
Tracking Range	士 60°
Driving System	Slew drive, 28VDC motor
Modules per Tracker	Max.90 modules per tracker
System Voltage	1000 V or 1500 V
Ground Coverage Ratio	≥ 25%
Power Consumption	0.2-0.5kWh/day
Power Supply Mode	Powered by PV strings, back-up lithium battery
Standard Design Wind Speed	18m/s
Module Supported	All commercially available modules
Operation Temperature	-40℃ - 70℃
Control Algorithm	Astronomical algorithms + Tilt sensor close loop
Tracking Accuracy	≤ 1°
String-Powered	Yes
Backtracking	Yes
Communication Options	LoRa wireless /RS 485 cable
Night Position	Yes

Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
